P2.85 Display Module Full Front Access 320x320mm For Informational Displays

Brand Name : VW

Model Number : P2.85

Certification : CE, EMC, LVD, ROHS, FCC

Place of Origin : CN

MOQ : Negotiate

Price : Negotiate

Payment Terms : T/T

Supply Ability : 2000sqm/month

Delivery Time : 15 work days

Packaging Details : plywood case, carton box

Product Name : P2.85 Display Module Full Front Access 320x320mm For Informational Displays

Pixel Pitch : 2.85mm

LED Type : SMD1415

Maintenance : Full front access

Brightness : 5000 nits

Refresh Rate : 3840Hz

Module Material : Die-casting aluminum

Control System : NovaStar

Contact Now

P2.85 Display Module Full Front Access 320x320mm For Informational Displays

Product Description:

P2.85 Outdoor LED Display Module is designed to deliver exceptional visual performance in a variety of outdoor settings. With a pixel pitch of 2.85mm, this module ensures that images are displayed with high clarity and detail, capturing the attention of viewers from a distance.

This model is crafted with a die-casting aluminum cabinet, which is not only lightweight but also provides a high level of durability. The cabinet's design facilitates easy installation and integration into various structures, such as building facades or freestanding frames.

Features:

Die-casting aluminum:Light and durable die-casting aluminum panel makes accurate assembling of corresponding hole position
Front access:Magnetic led modules strongly connect to the module frame. Safety rope is optional to tighten the connection.
Power box integration:The power supply, receiving card and hub board are simplied into a small power box. The module can work individually.
Curved video wall:The 45° edges modules are compatible with simple customized metal cabinet by magnets, which allows the module to build curved led walls.
2-in-1 transmiting cable:Customized 2 in 1 cable allows the led screen to transmit the current and signal simultaneously.

P2.85 Display Module Full Front Access 320x320mm For Informational Displays

Technical Parameters:

Technical Parameters	Outdoor LED Display Module
Product Model:	SMART BLOCK
Pixel Pitch:	2.85 mm
LED Type:	SMD1415
Pixel Density:	122500 dots/sqm
Cabinet Dimension:	320x320mm
Module Resolution:	112*112
Module Weight:	1.54 kg
Module+Frame Weight:	2.22 kg
Module Material:	Die-casting aluminum
Driving Type:	1/16
Brightness:	5000 nits
Max/Avg Power:	800/280 W/m2
Maintenance:	Front service
Environment:	Outdoor Use
IP Rating:	IP67
Refresh Rate:	>3840 Hz
Installation Type:	Mounting/Hanging
Gray Scale:	16 bits
Viewing Angle:	H:140°；V:160°
Operational Temp:	-30℃~+60℃
Operational Humidity:	10%~80% RH

Apllication:

This product can be used for advertising, informational displays, and even as a background for events and performances. With its high brightness and resolution, it can easily attract the attention of passersby and deliver your message effectively.

P2.85 Display Module Full Front Access 320x320mm For Informational Displays

FAQ:

Q1: How can I get technical support?
A1: We treasure every customer that shake hands with our Visual World. We offer you TEAMVIEWER help by Online Video and can send professional engineer to your city to offer on-site guide.

Q2: What about your service?
A2: We can offer a complete LED design solution for your LED project before confirming the order.
We can instruct you how to use, configure your LED display, and do some maintenance with spare parts. Also, we can send professional engineer to your city to offer on-site guide and offer training. Mostly, our LED display do not have big problems within warranty time.

Q3: How to operate and use it?
A3: It can by controlled by PC and Smartphone very easily.
Welcome to inquiry for more information. We provide video guidance and remote assistance.

Q4: Are you a manufacturer or a trading company? Do you have your own factory and R&D team?
A4: We are a leading LED display manufacturer with over 10 years of experience, boasting a modern production facility and a professional R&D team. This ensures direct control over product quality, cost, and production cycle, enabling us to provide our customers with the most competitive prices and reliable OEM/ODM services.

Q5: What is the minimum order quantity (MOQ)? Do you support sample orders?
A5: We understand the need for new customers to test products. We support sample orders, with an MOQ typically of one standard carton or one minimum order unit.
For bulk orders, we offer more competitive pricing. Specific MOQs are negotiable based on product model.
